| Image Sensor |
Type |
22.3 mm x 14.9 mm CMOS |
| Effective Pixels |
Approx. 24.10 megapixels |
| Total Pixels |
Approx. 25.80 megapixels |
| Aspect Ratio |
3:02 |
| Low-Pass Filter |
Built-in/Fixed |
| Sensor Cleaning |
EOS integrated cleaning system |
| Colour Filter Type |
Primary Colour |
| Image Processor |
Type |
DIGIC 8 |
| Lens |
Lens Mount |
EF and EF-S mount |
| Focal length |
Approx. 1.6x the focal length of the lens |
| Image Stabilisation |
Optical Image Stabilizer on compatible lenses |
| Focusing |
Type |
Via optical viewfinder: TTL secondary image-forming phase-difference detection system with AF-dedicated sensor.
Via LiveView on LCD screen: Dual Pixel CMOS AF System. Phase detection pixels built onto imaging sensor |
| AF System / Points |
Via optical viewfinder: 9-point Center AF point is AF cross-type supporting f/5.6. Center AF point is vertical line-sensitive supporting f/2.8. Other AF points are vertical line-sensitive or horizontal line-sensitive AF supporting f/5.6.
Via LiveView on LCD screen: Maximum 143 AF points via camera automatic selection 3 Freely position AF point/1 AF Zone max 3,975 points via manual selection |
| AF working range |
Via optical viewfinder: EV -0.5 – 18 (center AF point)4 EV 0.5 – 18 (other AF points)
Via LiveView on LCD screen: EV -4 – 18 (f/1.2 at 23 °C & ISO 100) with One-Shot AF |
| AF Modes |
AI Focus, One Shot, AI Servo (AI Servo II algorithm) |
| AF Point Selection |
Via optical viewfinder:
Automatic selection: 9 point AF
Manual selection: Single point AF |
| Exposure Control |
Metering modes |
Via optical viewfinder:
63-zone dual-layer metering sensor with Evaluative, partial, spot (centre only) and centre-weighted average available
Via LiveView on LCD screen:
(1) Evaluative metering (384 zones)
(2) Partial metering (approx. 5.5 % of LCD screen)
(3) Spot metering (approx. 3.7 % of LCD screen)
(4) Center-weighted average metering |
| Metering Range |
Via optical viewfinder: EV 1 – 20 (at 23 °C with 50 mm f/1.4 lens ISO 100) Via LiveView on LCD screen: EV -2 – 20 (at 23 °C, ISO 100, evaluative metering) |
| AE Lock |
Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE Lock Button in creative zone modes. |
| Exposure Compensation |
EV in 1/3 or 1/2 stop increments (can be combined with AEB).B21 |
| AEB |
3 shots +/-2 EV 1/3 or 1/2 stop increments |
| ISO Sensitivity |
Auto (100-25600), 100-25600 (in whole stop increments)
ISO can be expanded to H: 51200
During Movie shooting: Auto (100-12800), 100-12800 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 25600. 4K Movie Max. 6400 |
| Shutter |
Type |
Electronically-controlled focal-plane shutter |
| Speed |
30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode) |
| White Balance |
Type |
Automatic white balance with the imaging sensor |
| Settings |
AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten light, White, Fluorescent light, Flash, Custom, Colour Temperature Setting. White balance compensation: 1. Blue/Amber bias +/-9 levels. 2. Magenta/ Green bias +/-9 levels |
| Custom White Balance |
Yes, 1 setting can be registered |
| Interface |
Computer |
Hi-Speed USB |
| Wi-Fi |
Wi-Fi (2.4GHz) Channels: IEEE802.11b, IEEE802.11g, IEEE802.11n |
| Wi-Fi Security |
Camera Access Point: WPA2-PSK with AES encryption or open
Infrastructure: Shared key, with WEP encryption, WPA-PSK/WPA2-PSK with TKIP/AES encryption or open |
| Bluetooth |
BLE (Bluetooth Low Energy Technology) |
| Other |
Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible), External microphone (3.5 mm Stereo mini jack) |
| Software |
Image Processing |
Digital Photo Professional 4 (RAW Image Processing) |
| Other |
EOS Utility
EOS Lens Registration Tool
EOS Web Service Registration Tool
EOS Sample Music
Picture Style EditorCamera Connect app available on iOS and Android devices |
| Power Source |
Batteries |
1 x Rechargeable Li-ion Battery LP-E17 |
| Battery life |
Viewfinder: Approx. 1070 (at 23°C, AE 50%, FE 50%) (5)
Viewfinder: Approx. 1020 (at 0°C, AE 50%, FE 50%)
LiveView: Approx. 320 (at 23°C, AE 50%, FE 50%)
LiveView: Approx. 300 (at 0°C, AE 50%, FE 50%) |
| Battery Indicator |
4 levels |
| Power Supply & Battery Chargers |
Battery charger LC-E17E |
